Brand:
Mahle
Manufacturer's Part Number:
SBC550000F05
Part Type:
Pistons
Product Line:
Mahle PowerPak Piston and Ring Kits
Summit Racing Part Number:
MLE-SBC550000F05
Piston Rings Included:
Yes
Bore (in.):
4.000 in.
Bore (mm):
101.600mm
Stroke:
3.480 in.
Rod Length:
5.700 in.
Piston Style:
Flat top, with two valve reliefs
Piston Material:
Forged aluminum
Compression Height (in.):
1.550 in.
Piston Head Volume (cc):
+5.00cc
Wrist Pin Style:
Press-fit or floating
Wrist Pin Retainers Included:
Yes
Wrist Pin Included:
Yes
Pin Diameter (in.):
0.927 in.
File Fit:
Yes
Gapless:
No
Top Ring Thickness:
1.5mm
Top Ring Material:
Ductile iron
Top Ring Facing Material:
Plasma-moly
Second Ring Thickness:
1.5mm
Second Ring Material:
Cast iron
Second Ring Facing Material:
Cast iron
Oil Ring Thickness:
3.0mm
Oil Ring Material:
Carbon steel
Oil Ring Facing Material:
Chrome
Oil Ring Tension:
Standard
Remanufactured:
No
Quantity:
Sold as a set of 8.
